Alloy Wire inspecciona todas las fases de la producción y nuestro equipo de pruebas puede verificar la tolerancia del alambre/cinta/listón/sección/perfil, la calidad de la superficie, la circularidad, las propiedades de resistencia y la tensión necesaria para el punto de rotura.
Consulte nuestras tolerancias estándar más abajo.
Podemos ofrecer tolerancias más ajustadas; indíquenos la tolerancia que necesita.
| Tolerancias del diámetro del alambre | |||||
|---|---|---|---|---|---|
| mm | inch | ||||
| diámetro del alambre | hasta (no inclusive) | Tolerancia | diámetro del alambre | hasta (no inclusive) | Tolerancia |
| 0.0254 | 0.203 | ± 0.0051 | .001 | .008 | ± .0002 |
| 0.203 | 0.376 | ± 0.0076 | .008 | .015 | ± .0003 |
| 0.376 | 0.813 | ± 0.0100 | .015 | .032 | ± .0004 |
| 0.813 | 1.220 | ± 0.0127 | .032 | .048 | ± .0005 |
| 1.220 | 2.030 | ± 0.0152 | .048 | .080 | ± .0006 |
| 2.030 | 3.250 | ± 0.0203 | .080 | .128 | ± .0008 |
| 3.250 | 4.470 | ± 0.0254 | .128 | .176 | ± .0010 |
| 4.470 | 5.890 | ± 0.0381 | .176 | .232 | ± .0015 |
| 5.890 | 8.000 | ± 0.0510 | .232 | .315 | ± .0020 |
| 8.000 | 10.00 | ± 0.0635 | .315 | .395 | ± .0025 |
| 10.00 | 21.00 | ± 0.0762 | .395 | .827 | ± .0030 |
| Tolerancias de ovalidad del alambre | |||||
|---|---|---|---|---|---|
| mm | inch | ||||
| diámetro del alambre | hasta (no inclusive) | Tolerancia | diámetro del alambre | hasta (no inclusive) | Tolerancia |
| 0.0254 | 0.0508 | ± 0.0051 | .001 | .002 | ± .0002 |
| 0.0508 | 1.02 | ± 0.0076 | .002 | .040 | ± .0003 |
| 1.02 | 2.03 | ± 0.0100 | .040 | .080 | ± .0004 |
| 2.03 | 4.47 | ± 0.0127 | .080 | .176 | ± .0005 |
| 4.47 | 8.00 | ± 0.0152 | .176 | .315 | ± .0006 |
| 8.00 | 21.00 | ± 0.0203 | .315 | .827 | ± .0008 |
| Tolerancias del alambre plano | |||
|---|---|---|---|
| mm | inch | ||
| Dimensiones | Tolerancia | Dimensiones | Tolerancia |
| Width | ± 5% | Width | ± 5% |
| Thickness | Thickness | ||
| 0.20 and below | ± 0.0100 | .008 and below | ± .0004 |
| over 0.20 | ± 5% | over .008 | ± 5% |
| Tolerancias de Alambre en forma | |||||
|---|---|---|---|---|---|
| mm | inch | ||||
| Tamaño de la sección | hasta (no inclusive) | Tolerancia | Tamaño de la sección | hasta (no inclusive) | Tolerancia |
| up to | 2.0 | ± 0.04 | up to | .787 | ± .0016 |
| 2.0 | 4.0 | ± 0.07 | .0787 | .157 | ± .0027 |
| 4.0 | and above | ± 0.15 | .157 | and above | ± .0059 |
| Tolerancias de longitud recta | |||||
|---|---|---|---|---|---|
| mm | inch | ||||
| Diámetro | Longitud | Tolerancia | Diámetro | Longitud | Tolerancia |
| up to 2.5 | up to 1000 | ± 1.00 | up to .098 | up to 40 | ± .040 |
| up to 2.5 | 1000 – 2000 | ± 2.00 | up to .098 | 40 – 80 | ± .080 |
| up to 2.5 | 2000 – 3000 | ± 2.50 | up to .098 | 80 – 120 | ± .098 |
| 2.5 – 5.0 | up to 1000 | ± 2.00 | .098 – .197 | up to 40 | ± .080 |
| 2.5 – 5.0 | 1000 – 2000 | ± 2.50 | .098 – .197 | 40 – 80 | ± .098 |
| 2.5 – 5.0 | 2000 – 3000 | ± 3.00 | .098 – .197 | 80 – 120 | ± .120 |
| 5.0 – 12.0 | up to 1000 | ± 4.00 | .197 – .472 | up to 40 | ± .160 |
| 5.0 – 12.0 | 1000 – 2000 | ± 5.00 | .197 – .472 | 40 – 80 | ± .200 |
| 5.0 – 12.0 | 2000 – 3000 | ± 6.00 | .197 – .472 | 80 – 120 | ± .240 |
| Tolerancias de resistencia eléctrica | |||||
|---|---|---|---|---|---|
| mm | inch | ||||
| Diámetror | hasta (no inclusive) | Tolerancia | Diámetror | hasta (no inclusive) | Tolerancia |
| 0.0254 | 0.0508 | ± 12% | .001 | .002 | ± 12% |
| 0.0508 | 0.076 | ± 10% | .002 | .003 | ± 10% |
| 0.076 | 0.15 | ± 7% | .003 | .006 | ± 7% |
| 0.15 | ± 5% | .006 | ± 5% | ||
| Flat wire | ± 5% | Flat wire | ± 5% | ||
